H20 Timber Beam

H20 timber Beam, H16 timber beam, H20 timber beam, H24 timber beam[10-05-12 14:36:21]

H20 Timber Beam with plastic protection

Our H timber beams are composed of solid wood (Chinese pine, radiate pine, other pine) or LVL flange, and solid plywood, particle board or OSB web.

H timber beam is mainly used in the erection of horizontal formword system, vertical formwork system, column formwork system and other ferroconcrete panel system.

Plastic capped ends: with the protection of plastic caps, H beams can bear commonly direct clash and frication, while their prefect and conspicuous appearances are really popular.

1. Our products are bonded with special glue for outdoor constructional wood with Dyneafenol-Resorsinol-Formaldehyd (PRF).

2. Surface coat is rainproof, antispetic and antifreezing, etc.

3. Special ends design endow our products with effective protection.

Standard	200 in height, 80 in width
Flange	solid sawn pine lumber flange
Thickness of flange	40mm
Web	Pine plywood web
Thickness of web	25 or 29mm
Glue	WBP phenolic resin
Painting	Yellow, waterproof, fireproof, rot-proof and frozen-proof
Weight per running meter	5.2-6.5kg
Bending moment	max. 5kN/m
Shear force	min 11.0kN
Bending	max 1/500
Available Length	180 – 245 – 290 – 330 – 360 – 390 – 420 – 450 – 460 – 480– 590, maximum 600(CM)

Appropriate structure reduce deficency of wood itself while outstand its property of high strength and high tenacity.

Uniform standardized specification and lighter weight simplify construction process and even expedite construction. It's easy to deliver, assemble and disassemble.

The scientifically perfect system structure design increase H beams recycling.
