Plastic welding & cutting machine

Welding & cutting machine, High frequency welding and cutting machine, High frequency PVC,EVA,PUwelding and cutting machine, High frequency welding and cutting machine, High frequency welding and cutting machine, High frequency welding and cutting machine[09-01-06 13:21:28]

High frequency simultaneous welding and cutting machine

High frequency welding and cutting machine has wide applications. This type of High frequency welding and cutting machine inherits all the merits of the original model of High frequency welding and cutting machine, enhanced by new technology.

Compared with other High frequency welding and cutting machine, our High frequency welding and cutting machine enjoys many advantages including: more reasonable structure, more compact appearance, smoother operating, higher efficiency and is easy to operate and maintain. High frequency welding and cutting machine has wide adoptability, is an ideal High frequency welding and cutting machine for you to convert into production. High frequency welding and cutting machine that you need is just we can supply. We are one of the most famous High frequency welding and cutting machine exporters in China. We have been supplying a whole set of High frequency welding and cutting machine for overseas customers. We would like to provide maximum customer satisfaction at lowest possible cost and best after-sale service. If you need High frequency welding and cutting machine, please feel free to contact us.

Features:

The high efficiency machine for simultaneous welding and cutting process for materials of PVC, EVA, PU, Interlinint, Synthetic leather.
Application
- Trade mark labels, Footwear, Wrist-watch band, Belt, Package bag, Toothbrush packing, Camera bag, CD bag...

Specification of high frequency welting & cutting machine
Specification of high frequency welting & cutting machine

Model	WE-0805	WE-1005	WE-805CAS	WE-1515CAS
H.F. Out-Put Power	8 KW	10 KW	8 KW	15 KW
Oscillation Frequency	27.12 MHZ	27.12 MHZ	27.12 MHZ	27.12 MHZ
Oscillation Tube	7T69RB	E3069	7T69RB	8T85RB
Voltage	To be arranged	To be arranged	To be arranged	To be arranged
Max Gap of Electrodes (mm)	100	100	100	100
Press Stoke (mm)	60	60	200	200
Upper Electrodes Size (mm)	200 x 300	250 x 350	300 x 350	350 x 450
Lower Electrodes Size (mm)	250 x 350	300 x 500	350 x 400	400 x 550
ARC Control	High sensitive	High sensitive	High sensitive	High sensitive
Max. Press (KG/CM²)-Hydraulic	5,000	5,000	5,000	15,000
Operation	2 Welding Head	2 Welding Head	Single head with 2 automatic slide table	Single head with 2 automatic slide table

After saling High frequency welding and cutting machine, if necessary, We will send one or two engineers to set up and commissioning of the High frequency welding and cutting machine until it running in normal state. During the time your workers who will operate the High frequency welding and cutting machine will be trained.
