Woodworking Planer
Our Woodworking machine is intended to process wood in modern industry. These machines are powered by electric motors and are used extensively in woodworking. The whole machinery series include grinding machines, moulder machine, surface planer, circular saw, milling machine, rectangular Tenoner, oscillation mortiser, belt sanding machine, finger joint clamp, sharper and more. |
|
|
|
Double-side moulder series,woodworking machine,Model: MBK206F Technical data of Model MBK206F: Working width: 630mm,Working thickness: 10-170mm,Max planning capacity each time: up/5mm, down/3mmSpeed of main spindle : 4800 rpm,Feed speed: 5.3—20m/min,Toatl power: 21KW,Overall dimension: 2530 x 1180 x 1830mm,Weight: 3200kg |
|
|
MB 206F Double-side moulder serious,woodworking machine Technical data of Model: MB206F:Working width: 630mm,Working thickness: 10-170mm,Max planning capacity each time: up/5mm, down/3mm,Speed of main spindle : 4800 rpm,Feed speed: 5.3—20m/min,Toatl power: 21KW,Overall dimension: 2530 x 1180 x 1830mm,Weight: 3200kg |
|
|
MBZ 4016CX5A Four-side Moulder,woodworking machine Technical Data of Model: MBZ 4016CX5A: Working width: 20-160mm,Working thickness: 8-100mm, Max planning capacity each time: 5mm, Speed of main spindle : 6800 rpm,Feed speed: 6-24m/min, Toatl power: 24.5KW, Overall dimension: 3150 x 1450 x 1600mm, Weight: 2650kg |
|
|
MBQ616FX6A Four-side moulder,woodworking machine Technical Data of Model MBQ616Fx6A: Working width: 20-160mm, Working thickness: 8-100mm, Max planning capacity each time: 5mm, Speed of main spindle : 6800 rpm, Feed speed: 6-24m/min, Toatl power: 31KW, Overall dimension: 3720 x 1600 x 1700mm, Weight: 3700kg. |
|
|
Single-side surface planer thicknesser, MB 104B Surface planer Thicknesser, Woodworking machine. Technical Data of Model MB104B: Working width: 400mm, Working thickness: 7-180mm, Max planning capacity each time: 7mm, Speed of main spindle : 5500 rpm, Feed speed: 8.5-14m/min, Toatl power: 4KW, Overall dimension: 890 x 770 x 1250mm, Weight: 500kg |
|
|
MB 1013A Surface planer, Woodworking machine. Technical Data of Model MB1013A: Working width: 1300mm,Working thickness: 10-120mm, Max planning capacity each time: 2/1000, Speed of main spindle : 4000 rpm, Feed speed: 6.8—8.4m/min, Toatl power: 14.55KW, Overall dimension: 2150 x 1350 x 1680mm, Weight: 2180kg. |
|
|
MJ153B/MJ154C Woodworking saw series,Woodworking machine Technical Data of Auto-feed saw MJ153B: Working width: 460mm, Working thickness: 85mm, Saw blade diameter: 205-305mm, Speed of main spindle : 4500 rpm, Feed speed: 12/16/19/24m/min, Toatl power: 8.25KW, Overall dimension: 1450 x 1040 x 1350mm, Weight: 920kg. |
|
|
MJ164A Circular saw,Woodworking machine Technical Data of Model CIRCULAR SAW MJ164A: Working width: 660mm, Working thickness: 120mm, Saw blade diameter: 355-455mm, Speed of main spindle : 3000 rpm, Feed speed: 8-30m/min, Toatl power: 13.2KW, Overall dimension: 2250 x 1680 x 1550mm, Weight: 1750kg. |
|
|
MULTI-BLADE SAW MACHINE ,MJ 162 B Multi-blade woodworking saw, woodworking machine. Technical Data of Model Multi-blade circular saw MJ162B: Working width: 200mm, Working thickness: 10-75mm, Saw blade diameter: 305mm, Speed of main spindle : 4500 rpm, Feed speed: 6-24m/min, Toatl power: 24.6KW, Overall dimension: 2920 x 1080 x 1480mm,Weight: 1900kg |
|
|
MJ143E Multi-blade woodworking saw, Woodworking machine Technical data of Model MJ143E: Working width: 300mm,Working thickness: 10-120mm, Saw blade diameter: 380mm ,Speed of main spindle : 4000 rpm, Feed speed: 7.5-30m/min, Toatl power: 39.6KW, Overall dimension: 2300 x 1500 x 1450mm, Weight: 2300kg. |
|
|
woodworking milling machine ,MXH 5116E milling machine,Woodworking machine Technical Data of vertical single-spindle machine MXH5116E: working size: 1100 x 670mm, max working thickness: 140mm (height), main spindle diameter: 40mm, speed of main spindle: 10000/6600, total power: 5.5KW, overall dimension: 1100 x 670 x 1150mm, weight: 480kg. |
|
|
MX5319A Vertical milling machine, woodworking machine. Technical Data of vertical milling machine MX5319A: working size: 1600 x 820mm, max working thickness: 120mm (height), main spindle diameter: 35mm, speed of main spindle: 9500, total power: 8KW, overall dimension: 1600 x 820 x 1020mm, weight: 800kg |
|
|
MX 3768A Rectangular Tenoner,Woodworking machine. Technical Data of Rectangular tenoner MX3768A: working size: 1000 x 250mm, max working thickness: 70mm (depth), main spindle diameter: 13mm, speed of main spindle: 9500, total power: 3KW, overall dimension: 1530 x 1200 x 1180mm, weight: 590kg |
|
|
MX 3810B Oscillation mortiser, woodworking machine. Technical Data of Oscilating mortiser MX3810B: working size: 1000 x 250mm, max working thickness: 70mm (depth), main spindle diameter: 40mm, speed of main spindle: 9500, total power: 4.5KW, overall dimension: 1600 x 1300 x 1350mm, weight: 900kg |
|
|
SQC630R-RP wide belt sanding machine, Woodworking machine. Technical Data of Wide double-belt sander SQC630R-RP: Working width: 50—630mm, Max working thickness: 3-110mm, Belt Speed: 20/14, Feed speed: 4-18m/min, Total power: 21KW, Overall size: 1110 x 1650 x 1990 mm, Weight: 1500kg |
|
|
SQC 1300R-Rp Wide belt sanding machine, Woodworking machine Technical Data of wide double-belt sander SQC1300R-PR: Working width: 50—1300mm, Max working thickness: 3-120mm, Belt Speed: 20/14, Feed speed: 6--30m/min, Total power: 56KW, Overall size: 2600 x 2020x 2130 mm, Weight: 2980kg. |
|
|
wood laminating machines,Woodworking machine. |
|
|
MX 3515E Finger Jiont Shaper, Wood working machine. Technical Data of Finger joint shaper MX3515E: working width: 400mm, max working thickness: 150mm (height), saw blade diameter: 300mm, max speed of main spindle: 5600, total power: 9.7KW, overall dimension: 1580 x 1320 x 1170 mm, weight: 680kg. |
|
|
MH 1526 B Finger Joint Clamp, Wood working machine. Technical Data of Finger joint clamp MH1526B: working width: 2600 x 120 mm, max working thickness: 50 mm (height), saw blade diameter: 250mm, max speed of main spindle: 4000 ,total power: 4.4KW, overall dimension: 4000 x 800 x 1350 mm,weight:650kg |
After saling wood working machine, We will send one or two engineers to test the wood working machine until it running in normal state. Your local staff will also be trained during the assembly.
